KUKA KR 30

The highly flexible and durableKUKAKR30handles diverse applications. Its modular design allows for simple payload and reach modifications. With a small footprint and variable mounting options, theKR30KRC2fits the bill for space-efficiency and versatility. TheKR30KRC2robot is easily customized for different projects and requirements. It is capable of low to medium payloads, and powerful, accurate movement.

TheKR30JETrobot system is also available. This robot is light weight and extremely fast. It has a linear axis, jointed-arm andJETTRACKaxis module that helps to free up valuable floor space. The robot knee can be mounted overhead or on the wall, providing optimum axial symmetry to ensure the robot’s reach, deep into machines.

The modular structure of theKR30JETenables execution of the individual user and task-specific program sequences. Up to two robots can be deployed on theJETtraversing axis, making it possible to tend several machines or positions at the same time to further optimize the production process.

There is a wide range of gantry variants and a specially adapted linear unit to ensure speed and workspace are maximized. This system can be easily adapted to your current needs because of the overhead or side mounting options. TheKR30JEThas a0.07毫米的重复性,1682.5mm reach, and can cover distances of up to30meters. It can take parts out of machines from above with speed, precision, and high repeatability.
